| Product model | usage method | Rated voltage (v) | power (kw) | Rated lifting capacity (kg) | Lifting speed (m/min) | Lifting height (m) | Diameter of steel wire rope (mm) |
| Quick type 500-1000KG | Single rope | 380 | 1.7 | 300 | 24 | 1-2000 | 6.0 |
| Double rope | 600 | 12 | |||||
| Quick type 500-1000KG | Single rope | 220 | 3.0 | 300 | 28 | 1-2000 | 6.0 |
| Double rope | 600 | 14 | |||||
| Quick type 600-1200KG | Single rope | 380 | 2.2 | 350 | 24 | 1-2000 | 6.0 |
| Double rope | 700 | 12 | |||||
| Quick type 600-1200KG | Single rope | 220 | 3.0 | 350 | 24 | 1-2000 | 6.0 |
| Double rope | 700 | 12 | |||||
| Normal type 500-1000KG | Single rope | 380 | 1.7 | 500 | 16 | 1-2000 | 6.0 |
| Double rope | 1000 | 8 | |||||
| Normal type 600-1200KG | Single rope | 220 | 3.0 | 500 | 16 | 1-2000 | 6.0 |
| Double rope | 1000 | 8 | |||||
| Normal type 600-1200KG | Single rope | 380 | 2.2 | 600 | 14 | 1-2000 | 6.2 |
| Double rope | 1200 | 7 | |||||
| Normal type 600-1200KG | Single rope | 220 | 3.0 | 600 | 14 | 1-2000 | 6.2 |
| Double rope | 1200 | 7 | |||||
| Quick type 750-1500KG | Single rope | 220 | 4.0 | 400 | 24 | 1-2000 | 6.0 |
| Double rope | 800 | 12 | |||||
| Quick type 750-1500KG | Single rope | 220 | 4.0 | 750 | 14 | 1-2000 | 7.0 |
| Double rope | 1500 | 7 |
